Drawing To Model/Reverse Engineering

At CAD9 Design, we specialize in transforming 2D drawings and samples into precise CAD models, with a strong emphasis on reverse engineering. This integrated approach involves analyzing existing products or legacy designs, whether they are hand-drafted drawings or physical samples, to create accurate and detailed digital representations.

Our reverse engineering process adds significant value for companies aiming to modernize their design workflows and seamlessly incorporate older designs into contemporary computer-aided manufacturing (CAM) systems. By meticulously capturing the dimensions and specifications of existing items, we help businesses streamline production, enhance design accuracy, and minimize errors that often arise from manual interpretations.

For machine shops, we can take traditional designs and expertly model them for use in platforms like MasterCam. This includes creating precise models of stock or customer castings, finished parts, and all intermediary stages, tailored to your specific production needs. We also offer the capability to color-code models by operation or cutter type, further optimizing your manufacturing processes.

For product manufacturers, our reverse engineering services allow you to work from hand drawings or even existing products to transition your ideas into prototyping without requiring internal modeling expertise or engineering resources.

Contact us today to see how we can integrate reverse engineering into your project, providing you with the accuracy and efficiency needed for today’s competitive market.
